Natrix IOM
Tightening Torque
• The tensioning station must be in the end position if
you want to take advantage of the maximum
tensioning distance.
•
The closed side of the link retainer must point in the
conveying direction.
Please Note: After the connection of the chain, check the aluminum profiles to ensure
they are square and at a right angle with the sorter framed.
Remove the aluminum slats and make sure that no dirt, tools, or loose screws can be found in
the sorter frame along its entire length.
Revision Date: 12/10/2014 Page 41 of 111
