111
23. INTERSECTIONS
PROCEDURE
1. In the second page of the OBS mode screen, press
[MENU], then select "Intersect.".
2. Enter the 1st point data and press [NEXT].
• When [LOAD] is pressed, registered coordinates can be
recalled and used.
"13.1 Entering Instrument Station Data and Azimuth
Angle PROCEDURE Reading in Registered
Coordinate Data"
• [REC]: records the coordinate value as a known point data.
• Press [MEAS] to observe the selected point.
• The tilt screen is displayed if the instrument is out of level.
Level the instrument.
"7.2 Levelling"
3. Enter the 2nd point data and press [OK].
• Press [MEAS] to observe the selected point.
4. Enter azimuth angle (or horizontal distance) of the 1st point
and 2nd point.
• Both the azimuth angle and horizontal distance of the 1st
(or 2nd) point cannot be input.
• When the cursor is on "Azmth1" or "Azmth2", [COORD] is
displayed. Press [COORD] to set the azimuth angle for
each point by inputting coordinates.
• Press [MEAS] to observe the selected point.
Intersect.
Traverse
Road
Xsection
D e f i n e 2 n d P T
Ep:
Np:
Zp:
1 1 2 . 7 0 6
1 0 4 . 0 6 9
1 1 . 7 7 5
RECLOAD MEAS OK
: 5 0 . 0 0 0 m
A z m t h 1
H . d i s t 1
A z m t h 2
H . d i s t 2
: < N u l l >
:
: 4 5 0 0 ’ 0 0 "
OK
1 s t P T
E p :
N p :
Z p :
0 . 0 0 0
0 . 0 0 0
< N u l l >
RECLOAD MEAS NEXT
To Next Page
