158
28. RECORDING DATA - TOPO MENU -
4. Check the input data, then press [REC].
5. To continue measurement, sight the next point, press
[MEAS], then perform steps 3 and 4 above.
• Pressing [AUTO] will start measurement, and
automatically record the measured results. It is convenient
to record measured data without setting the collimation
height, code and point name.
• Press [OFFSET] to start offset measurement.
6. Press {ESC} to quit measurement and restore <TOPO>.
Distance measurement data and coordinate data can be stored in the current JOB at the same time.
• Both distance measurement data and coordinate data are recorded as the same point name.
• Distance measurement data is recorded first, then coordinate data is recorded.
PROCEDURE
1. Press [TOPO] in the third page of OBS mode to display
<TOPO>.
Select “Dist + Coord” to display the measurement results.
2. Sight the point and press [MEAS] to begin the
measurement.
The measurement results are displayed.
3. Set the following items.
(1) Target height
(2) Point name
(3) Code
4. Check the input data, then press [REC].
5. Press {ESC} to quit measurement and restore <TOPO>.
28.6 Recording Distance and Coordinate Data
Dist + Coord
Note
View
Deletion
To Next Page
