Topcon GM-100 Series User Manual

156
28. RECORDING DATA - TOPO MENU -
3. Set the following items.
(1) Target height
(2) Point name
(3) Code
4. Check the input data, then press [REC].
5. Press {ESC} to quit measurement and restore <TOPO>.
Distance measurement data can be stored in the current JOB.
PROCEDURE
1. Press [MEAS] in the first page of OBS mode to perform
distance measurement.
"12.2 Distance and Angle Measurement"
2. Press [TOPO] in the third page of OBS mode. <TOPO> is
displayed.
Select “Dist data” to display the measurement results.
3. Set the following items.
(1) Target height
(2) Point name
(3) Code
4. Check the input data, then press [REC].
28.4 Recording Distance Measurement Data
TOPO JOB1
Occupy
Angle data
Dist data
Coord data
BS data
REC
ZA
HA-R
HR
PT
SD
