159
28. RECORDING DATA - TOPO MENU -
This procedure prepares notes data and records it in the current JOB.
PROCEDURE
1. Press [TOPO] in the third page of OBS mode to display
<TOPO>.
Select “Note”.
2. Enter the note data.
3. After inputting the note data, press [OK] to return to
<TOPO>.
• Maximum note length: 60 characters (alphanumeric)
It is possible to display the data within the current JOB that is selected.
• It is possible to search for data within the JOB to be displayed by point name. But the note data cannot be
searched.
• Known point data that are entered from an external instrument are not reviewed.
PROCEDURE Reviewing JOB data
1. Press [TOPO] in the third page of OBS mode to display
<TOPO>.
Select “View” to display the list of recorded points.
28.7 Recording Notes
28.8 Reviewing JOB Data
Dist + Coord
Note
View
Deletion
T r e e 0 1 L e f t
TOPO / Note
2
2
2
3
FIRST LAST SRCH
Occ
RED
Bkb
Ang.
Dist
Dist + Coord
Note
View
Deletion
