173
32.USING USB FLASH DRIVE
It is possible to read in/output data from/to a USB flash drive.
When using a USB flash drive, data is stored in the root directory. You cannot read/write data from/to
subdirectories.
When using the GM, an MS-DOS-compatible text file can be input/output.
When "S type" is selected, only files with an extension of "SDR" can be input/output. The GM cannot
display files with an extension other than "SDR" stored in a USB flash drive. Also, an output code data file
can be displayed only when "T type" is selected. (The same will apply to a case for saving a code while "S
type" is selected.)
You can neither save a file under the same name as a read-only file, nor change/delete the name of a read-
only file. (However, this varies depending on the model or software you are using.)
For "Communication Manual" that describes details on the communication formats used for inputting/
outputting data to/from a USB flash drive, please consult with your local dealer.
When using the GM, you can use a USB flash drive with the capacity of up to 8GB.
Do not remove the USB flash drive during data read/write. Doing so will cause data stored in the USB flash
drive or the GM to be lost.
Do not remove the battery or turn OFF the power during data read/write. Doing so will cause data stored in
the USB flash drive or the GM to be lost.
Waterproofing property for this instrument is not secured unless the battery cover and external interface hatch
are closed, and the connector caps are correctly attached. Do not use it with these open or loose, under the
condition where water or other liquid spills over the instrument.
The specification grade for water proofing and dust resistance is not guaranteed when using USB connector.
PROCEDURE
1. Open the external interface hatch.
2. Insert the USB flash drive in the respective slot.
32.1 Inserting the USB Flash Drive
External
interface
hatch
