207
36.CLOUD OAF
The GM has a function to update option authorization file (OAF) using the Cloud OAF system. The system
allows you to customize and configure the instrument according to your purpose. To update Cloud OAF, you
need to purchase a specific optional package in advance. Contact your local dealer for the details of the
available options and purchasing process.
• When updating the firmware, mount a fully charged battery to the total station or use the external battery
(optional accessory).
This section explains the procedures of offline Cloud OAF update. Save the update file downloaded from the
TSshield web site in an USB flash drive and insert it to the instrument.
• When updating, use a blank USB flash drive.
• A warning message may appear in step 3 depending on the browser in use or the settings of the PC; however,
the downloaded file does not have a problem.
Reference: On Internet Explorer
Click the [x] button to exit the message.
PROCEDURE
1. Access TSshield web site from your PC.
Press [More info] for the instrument on the
Dashboard to display <Instrument page>.
2. Press [Download] in the "General Information".
3. Save the update file (xx_xxxxxx.oaf) in the route
folder of a USB flash drive.
• If the destination to save downloaded files is not
changed, the downloaded file is saved in
"Download" folder.
36.1 Cloud OAF Offline Update
To Next Page
