27
8. POWER ON/OFF
PROCEDURE Power OFF
1. Press and hold (about 1 sec) the power key on the
operation panel.
• When there is almost no battery power remaining, the
battery icon in the Status icon will start to blink.In this event,
stop measurement, switch off the power and charge the
battery or replace with a fully charged battery.
• To save power, power to the instrument is automatically cut
off if it is not operated for a fixed period of time. This time
period can be set in "Power off" in <Instr.config.>.
"33.1 Observation Conditions - Angle/Tilt"
Reset button
If you are experiencing problems with the software, depress the reset button to reboot the program forcibly.
Use a provided hexagonal wrench (1.3 mm/1.5 mm) or a tapered rod like a pin to depress down the reset
button.
• Pressing down the Reset button may result in file and folder data being lost.
• Avoid using any sharp implement like a needle. Malfunction of the instrument could result.
Reset button
