Configuration
Topcon HiPer Lite and HiPer Lite+ Operator’s Manual
2-8
6. Select the Power output modes Slots drop-down list to set
power output on internal slots (Figure 2-6).
• On – all slots are powered if the receiver is turned on
• Off – internal slots will not be powered even if the
receiver is turned on
• Always – internal slots will be powered even if the
receiver is turned off
Figure 2-6. Select Power Output Modes – Slots
7. View the Voltages information (Figure 2-7 on page 2-9).
• External – displays the external power supply’s voltage
• On Board – displays the voltage drawn by the receiver
board
• Battery A – displays the voltage of battery A
• Battery B – displays the voltage of battery B
• Charger – displays the charger’s output voltage during
battery charging
