Topcon HiPer VR User Manual

Receiver Enclosure—Overview
2-4
P/N: 1023998-01
Getting Acquainted
Receiver Enclosure—Bottom Overview Labels
Attached to the bottom of the receiver enclosure are the regulatory and product identification labels.
The Product Identification Label contains the Serial Number (S/N) and Part Number (P/N)
(Figure 2-5) for the receiver.
Figure 2-5: Bottom Enclosure Overview with Product Identification and Regulatory Labels
Product Identification Label
Part Number
Serial Number
Regulatory Label

Topcon HiPer VR Specifications

General

Battery Life	Up to 10 hours
Ingress Protection	IP67
Internal Memory	8 GB
Signal Tracking	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Static Accuracy Horizontal	3 mm + 0.1 ppm
Static Accuracy Vertical	5 mm + 0.5 ppm
Communication	Bluetooth, Wi-Fi
Operating Temperature	-40°C to +65°C
Update Rate	20 Hz
