Topcon HiPer VR User Manual

Specifications
Bluetooth Module Details
9-8
P/N: 1023998-01
Bluetooth Module Details
Table 9-4 describes HiPer VR’s Bluetooth module specifications.
Connector Specifications
HiPer VR has one antenna connector for radio transmission/reception, and four data and port
connectors for power, serial communication, micro-USB, and the external GNSS antenna. The
LongLink and Bluetooth antennas are internal.
Radio (Modem) RF Connector
The modem connector (Table 9-5) is a reverse TNC connector for 915 radio, and a BNC connector for
UHF radio.
Effective Radio Link Rate 9600, 10200, 17000, 51000 bps, user selectable for FH915
Error Correction FEC (15.7), majority decoding
Antenna Type 1/2 wave articulating whip
Antenna Connector Reverse polarity TNC
Antenna Gain 2.5 dBi
Table 9-3. R2 Lite FH915 Internal Modem Board Specifications
Item Specification
Table 9-4. Bluetooth Module Specifications
Item Specification
Range Up to 50 meters/164.05 ft. (indoor);
Up to 328.1 meters/1000 ft. (outdoor)
Type Class 1
Service Classes Miscellaneous
Supported Profiles SPP, LongLink
Frequency Country Code North America and Europe
Table 9-5. Modem Connector Specifications
Modem Type Signal Type Dir Details
915 Reverse TNC Modem I/O I/O RF output from modem
antenna
UHF BNC Modem I/O I/O RF output from modem
antenna

Topcon HiPer VR Specifications

General

Battery Life	Up to 10 hours
Ingress Protection	IP67
Internal Memory	8 GB
Signal Tracking	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Static Accuracy Horizontal	3 mm + 0.1 ppm
Static Accuracy Vertical	5 mm + 0.5 ppm
Communication	Bluetooth, Wi-Fi
Operating Temperature	-40°C to +65°C
Update Rate	20 Hz
