Topcon HiPer VR User Manual

Battery LED
3-8
P/N: 1023998-01
Display Panel
Battery LED
The battery LED indicates the remaining charge of the internal battery. When using an external power
source, the LED turns solid green and begins to blink if the batteries are charging. See
Table 3-8 for
more information.
Table 3-8. Internal Battery LED Descriptions
Display LED Color Description
The receiver is on—and the internal battery is in use
Green Solid The charge is greater than 50%.
Yellow Solid The charge is between 10% and 50%.
Red Solid The charge is less than 10%.
The receiver is on—and the external power source in use
Green Solid The internal battery is fully charged.
Green Blink The internal battery is at greater than 50%
capacity; the battery is charging.
Yellow Blink The internal battery is at greater than 10%
capacity; the battery is charging.
Red Blink The internal battery is at less than 10%
capacity; the battery is charging.

Topcon HiPer VR Specifications

General

Battery Life	Up to 10 hours
Ingress Protection	IP67
Internal Memory	8 GB
Signal Tracking	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Static Accuracy Horizontal	3 mm + 0.1 ppm
Static Accuracy Vertical	5 mm + 0.5 ppm
Communication	Bluetooth, Wi-Fi
Operating Temperature	-40°C to +65°C
Update Rate	20 Hz
