Battery LED
3-9
P/N: 1023998-01
Display Panel
The receiver is off
Green Solid The receiver is connected to an external power
source, and the battery is fully charged.
Green Blink The receiver is connected to an external power
source, and the battery is at greater than 50%
capacity; the battery is charging.
Yellow Blink The receiver is connected to an external power
source, and the battery is at less than 50%
capacity; the battery is charging.
No Light The receiver is not connected to an external
power source.
Table 3-8. Internal Battery LED Descriptions
