Recording Data
7-2
P/N: 1023998-01
Collecting Data
To stop recording press the Power button three times in a row within 2 seconds, and make sure that
the REC LED is dark.
Recording Data Using Topcon Receiver Utility
To start recording data using TRU:
1. Press the Power button to turn on the receiver.
2. Wait for the Power LED to become solid green.
3. Launch TRU, and establish the connection with the receiver in the Receiver Managing mode.
See the TRU
Help for more information.
4. Click the File Explorer icon. The File Explorer screen appears (Figure 7-1).
5. Open the Logs tab. You can record up to 16 raw data files simultaneously, from
A
to
P
. For each
file you can use the its own default settings for logging.
Figure 7-1: Logs Tab of the File Explorer Screen
6. Right click on the desired file it to open the context menu.
7. Click Edit to open the Log screen, and specify individual settings such as Elevation Mask,
Prefix and Rotation Period.
With the Power button, you can record up to 16 raw data files.
