Cables
2-6
P/N: 1023998-01
Getting Acquainted
Figure 2-6: Power Charge Cable—US P/N 1005793-01
Figure 2-7: Power Charge Cable—Europe P/N 1005794-01
Alligator Clips Cable (Optional)
Connects any 12-volt DC power source to
the receiver via the SAE cable.
P/N 14-008025-01
SAE-to-SAE extension cable
(Optional)
Connects SAE connectors over longer
distances.
P/N 14-008022-01
External Antenna Cable (Optional)
Connects the receiver to an external Topcon
GNSS antenna.
P/N 1006447-01
Table 2-1. Receiver Cables
Cable Description Cable Illustration
