Topcon HiPer VR User Manual

Using an External Power Source
4-5
P/N: 1023998-01
Managing Power
To restore power to the receiver you will need to connect the receiver to an external power source:
a. Make sure the power cable is correctly connected to the power port of the receiver.
b. Align the keyways when connecting the power cable to the power port of the receiver.
c. The cable will click when it is secured in the port.
d. To remove the cable, push the cable in, then gently remove it from the power port.
Recharge the battery or connect it to an external power source using the charging
cables and power adapter shipped with the receiver. The time to fully charge the
battery at 77 degrees F (25 degrees C) is about 4 hours.

Topcon HiPer VR Specifications

General

Battery Life	Up to 10 hours
Ingress Protection	IP67
Internal Memory	8 GB
Signal Tracking	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Static Accuracy Horizontal	3 mm + 0.1 ppm
Static Accuracy Vertical	5 mm + 0.5 ppm
Communication	Bluetooth, Wi-Fi
Operating Temperature	-40°C to +65°C
Update Rate	20 Hz
