Topcon IS Series User Manual

13
1 NOMENCLATURE AND FUNCTIONS
Telescope grip
Telescope eyepiece
Plate level
Circular level
Instrument
height mark
Battery cover
Adjusting screw
for circular level
Power switch
Stylus pen
Battery cover lever
Operation keys
Display window
(With touch panel)
Cover sensor
(Inside the cover)
Power supply connector
Vertical jog
Vertical shuttle
Horizontal jog
Horizontal shuttle
Serial Signal Connector
Focus jog
Focus shuttle
Handle fixing screw

Topcon IS Series Specifications

General

Brand	Topcon
Model	IS Series
Category	Measuring Instruments
Language	English
