6 PARAMETERS SETTING MODE
6.1 Parameter Setting Options
6.1.1 Measurement
Factory default settings are indicated with underlines.
Menu Selecting Item Contents
MEASUREMENT1
MINI ANG READING NORM
/ MINI Select the minimum display angle reading unit.
FINE READING 1mm
/ 0.2mm Select 1mm/0.2mm for the minimum distance in fine mode.
TILT OFF/X-ON/XY
-ON Select the tilt sensor option for OFF, X-ON, XY-ON.
3AXIS
CONPENSATION
OFF
/ON
Select the error correction ON or OFF for collimation and
error adjustment.
Perform this item after complete Chapter 7.5 “Compensation
Systematic Error of Instrument” .
For more information, refer to Chapter 7.3.7 “Adjustment of
Vertical Angle 0 Datum” and Chapter 7.5.2 “Showing
Compensation Systematic Error of Instrument”
.
POWER ON MODE ANGLE/DIST
Select the measuring mode when the power is on to angle
measurement or distance measurement.
DIST MODE FINE
/CRS/cRS
After turning on the power, select the same measuring mode
(FINE/CRS/CRS10mm) as when distance measurement was
initially carried out.
DIST DISPLAY HD&VD/SD
After turning on the power, select the same measuring mode
(HD&VD/SD) as when distance measurement was initially
carried out.
V ANGLE Z0/H0
ZENITH
/
HORIZONTAL
Select the vertical angle reading for Zenith 0 or Horizontal 0.
DIST MEAS
NUMBER
REPEA
T/N TIME
After turning on the power, select the same measuring mode
(REPEAT/N TIME) as when distance measurement was
initially carried out.
NEZ / ENZ NEZ
/ ENZ
Select the display format in the coordinate measurement
mode for NEZ or ENZ.
W CORRECTION OFF/0.14
/0.20
Select the coefficient correction for refraction and earth
curvature. Selections for the refraction coefficient are; OFF
(No correction), K=0.14 or K=0.20.
S/A BUZZER OFF/ON Select the Audio tone OFF or ON for the Set Audio Mode.
MEASUREMENT2
TURN
FINE/NORMAL
/
COARSE
Select the stopping accuracy of automatic rotation to required
angle. FINE: 3” NORMAL: 5” COARSE: 10”
AUTO AIM
FINE
/NORMAL/
COARSE
Select the accuracy of automatic collimation.
START MODE
NORMAL
/
STD MEAS/
Ext.Link
Select the start mode after hardware reset or software reset.
This setting does not effect the resume mode.
EXTERNAL BATTERY
Li-ion
/12V BATTERY Select the external battery type.
