1 NOMENCLATURE AND FUNCTIONS
•
The symbol marks for Auto-tracking and Auto-collimating
1.2.4 Display keys
1.2.5 Shortcut Keys
Auto-collimating
(
Laser is emitting )
The instrument is in auto-collimating
status.
Auto-tracking
(
Laser is emitting )
The instrument is in auto-tracking
status.
Waiting (
Laser is emitting )
The instrument is in waiting status.
Searching (
Laser is emitting)
The instrument is searching a
prism.
Failure in auto-collimating.
(Laser is off)
The instrument could not find the
target prism during auto-collimating.
KeysName of Key Function
Auto-collimating
key
Tu rn the collimating ON/OFF.
ANG
Angle
measuring key
To be angle measuring mode.
Distance
measuring key
To be distance measuring mode.
Coordinate
measuring key
To be coordinate measuring mode.
REC REC key Result of measurement is transferred.
Software Reset [Shift]+[Func]+[ESC]
Windows Start Menu [Ctrl]+[ESC]
Shortcut Commands
Continue tapping on an item
or
[Alt]+Tap on an item
Windows CE
Task Manager
[Alt]+[TAB]
to switch to another active program or to END Task on running pro-
gram(s).
