1 NOMENCLATURE AND FUNCTIONS

1.17Using the USB Port

• Using ActiveSync

For Type mini B, refer to Chapter 2.9 “Active Sync”.

• Using a USB memory

Open the USB connector cover.

Insert a USB memory into the Type A side.

Conﬁrm that the USB memory has been recognized.

When using the USB port (mini B, Type A), do not rotate the instrument.

It will cause damage to the instrument, USB memory or F-25 cable.

USB

Type miniB (Active Sync)

Type A (USB Memory)
