Telescope
Length : 165mm
Objective lens : 45mm (EDM 50mm)
Magnification : 30
×
Image : Erect
Field of view : 1°30'
Resolving power : 3"
Minimum focus : 1.4m
Reticle illumination : Provided
Assist Focus
Method : Distance focus method or
Contrat pack detection method
Focus area : 5m - 1000m
Focus time : Within 4 - 5.2 sec.
Image Sensor
Wide
Pixel : 1.3M pixel(1280 x 1024) SXGA
Magnification : 0.5 / 1.0 / 2.0 / 4.0 / 8.0
Minimum focus : 2.0 m
Angle of field (Diagonal) : 33°
Telescope
Pixel : 1.3M pixel(1280 x 1024) SXGA
Magnification : 0.5 / 1.0 / 2.0 / 4.0 / 8.0
Minimum focus : 2.0 m
Angle of field (Diagonal) : 1°
Automatic Tracking / Collimating
Maximum Automatic Tracking speed : 15° /sec
Automatic Collimating area : ±5°
Automatic Tracking range *1) :
Automatic Collimation accuracy : 2” Standard deviation *2)
Search pattern : Pattern 1 / Pattern 2
Search range : Any value can be set, able to set (1° step)
Safety standard for Laser Beam : Class 1 (IEC Publication 825)
Class ll (FDA/BRH 21 CFR 1040)
*1) Condition : Normal (Visibility about 20km), except high humidity time.
Automatic Tracking range of Reflector tape will differ depending on the kind of reflector tape.
*2) The air condition is stable and prism is staying.
Automatic
Collimation / Tracking accuracy is available only for prism use except for reflector
tape.
Scanning
*1)
Range : 150m *2)
Speed : Max 20points/sec, Typical 10points/sec
Standard deviation : 5mm
Single 3D point accuracy : 12mm
*1) When using TopSURV scan function in non-stop mode
*2)Target color, atmospheric conditions and scanning angles will impact range.
Prism type 2, with 1 prism 8 to 1000 m (26 to 3,280ft)
Pinpole Prism , with 1 prism 5 to 600 m (16 to 1,960ft)
Prism Unit Type A6/A7 10 to 600 m (33 to 1,960ft)
Reflector tape (5cm
×
5cm) 10 to 50 m (33 to 164 ft)
To Next Page
