Power output modes
• The checkbox Ports A,B allows you to turn power on and off for ports A and B. The
corresponding receiver parameter is /par/pwr/out/ab.
• With the checkbox Port C you can turn power on and off on port C. The correspond-
ing receiver parameter is /par/pwr/out/c.
The two above-described parameters are applicable to the Odyssey receiver only.
• The list box Ports governs power output on serial ports:
♦ On – the power board will feed all available serial ports via the corresponding
pins when the receiver is turned on. If the receiver is turned off, there will not
be any power on the ports.
♦ Off – power, for all available serial ports, will be absent even if the receiver is
turned on.
♦ Always –all serial ports will be powered even if the receiver is powered off.
The Ports list box is associated with the receiver parameter /par/pwr/ports.
• With the Slots list box the user governs power output on the internal slots:
♦ On – means that all slots are powered if the receiver is turned on.
♦ Off – means that internal slots will not be powered even if the receiver is turned
on.
♦ Always – means that internal slots will be powered even if the receiver is turned
off.
The list box is associated with the receiver parameter /par/pwr/slots.
Turn on/off Slots
• Select the Slot 2, Slot 3 and Slot 4 checkboxes to enable the corresponding in-
ternal slots. These checkboxes correspond to the receiver parameters /par/pwr/switch
and /par/pwr/switch/N. The first parameter allows you to enable all slots simultaneously.
The second parameter allows you to enable only one slot at a time. Here N is the slot
number (2, 3, 4).
The list boxes Ports, Slots and the Turn on/off Slots group box, are
applicable to the HiPer and Odyssey-E receivers only.
If the checkbox Enable Low Power Mode is selected, the receiver’s processor will go into
low power consumption
mode. The corresponding receiver parameter is /par/lpm.
