Switching from Internal to External and vice versa may result in a temporary loss of lock to
satellites.
The External Frequency Source Parameters controls allow the user to adjust the pa-
rameters related to external frequency mode:
With the Ext. frequency value edit box the user specifies nominal external fre-
quency value. Here one can enter the values between 2 and 40 MHz. The default value
is 10 MHz. The box is associated with the receiver parameter /par/frq/ext.
The field Ext. frequency source status shows whether the external frequency
is being used or not:
off – indicates that the receiver is using the internal crystal oscillator.
wait – indicates that the receiver is waiting for the external frequency lock.
More precisely, this value will be returned in the following three cases:
1. If the external frequency oscillator is disconnected;
2. If the amplitude of input signal is too low;
3. If the actual external frequency is different from that specified in the Ext.
frequency value edit box.
locked – indicates that the receiver is using the external frequency.
The field is associated with the receiver parameter /par/frq/stat.
With the Ext. freq. signal amplitude field the user can estimate the external
frequency signal amplitude:
off – indicates that the internal oscillator is actually being used;
low – indicates that the external frequency signal’s amplitude is lower than
needed;
ok – indicates that the external frequency signal’s amplitude meets the specs.
This field correspond to the receiver parameter /par/frq/amp.
The Oscillator Offset Reduction group box allows the user to govern the behavior of the
internal crystal oscillator.
The Off radio button means that the oscillator frequency offset reduction mode is
turned off.
The Freq. Locked radio button means that the receiver will adjust the internal oscil-
lator's frequency until the measured frequency offset is reduced to zero. By using the
incoming satellite signals, the receiver will force the internal oscillator to generate a
very stable 20 MHz frequency signal. This frequency output is available via the corre-
sponding receiver output pin.
