Toshiba TOSVERT VF-AS3 User Manual

E6582062
4. [Basic operation] Operation methods of motor 4-8
4
9
How to use
For example, set preset speed operation in the following procedure.
1 Select Guidance function "2: Preset speed operation"
and press the [OK] key.
Parameters required for preset speed operation are
displayed as a group.
2 Press the [OK] key with <CMOd: Run command
select> on the top of the preset speed parameter
group screen selected.
The selection screen of <CMOd> is displayed.
3 When you select <CMOd> and press the [OK] key,
the screen returns to the preset speed parameter
group screen. Select the next parameter <FMOd:
Frequency command select 1> and press the [OK]
key.
By setting parameter groups similarly in turn, you
can set necessary parameters easily.
3.2 Preset speed guidance
3.3 Analog signal operation guidance
3.4 Motor 1,2 switching guidance
3.5 Motor parameter guidance
Top
0.0HzSTOP
14:33
Monitor
Guidance function
3.1 Embedded Ethernet
CMOd : Run command select
FMOd : Frequency command select 1
ACC : Acceleration time 1
dEC : Deceleration time 1
FH : Maximum frequency
Top
0.0HzSTOP
14:34
0
10
10.0s
10.0s
MXXX
80.0Hz
Monitor
0: Terminal
1: Operation panel,Ext panel
2: Embedded Ethernet
3: RS485 com (connector 1)
4: RS485 com (connector 2)
0.0HzSTOP
14:35
CMOd :Run command select
CMOd : Run command select
FMOd : Frequency command select 1
ACC : Acceleration time 1
dEC : Deceleration time 1
FH : Maximum frequency
Top
0.0HzSTOP
14:35
0
1
10.0s
10.0s
MXXX
80.0Hz
Monitor

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
