4. [Basic operation] Operation methods of motor 4-10
4
9
4) Basic parameter
Basic parameters for inverter operation are
displayed.
For details, refer to [5. 3], [5. 4], [11. 2].
5) Extended parameter (F---)
Extended parameters used for complicated
operation, detailed setting, and special
applications, etc. are displayed.
Extended parameters are represented as "F" and a
3-digit number.
For details, refer to [5. 4], [Chapter 6], [11. 3].
6) Advanced parameter (A---)
Parameters of My function, etc. that allows
simplified programming are displayed.
Advanced parameters are represented as "A" and
a 3-digit number.
For details, refer to [11. 4].
7) Communication parameter (C---)
Parameters with communication function are
displayed.
Communication parameters are represented as
"C" and a 3-digit number.
For details, refer to [11. 5].
8) Changed parameters search & edit <GrU>
Parameters with values different from the default
setting are searched, and the titles and setting
values of such parameters are displayed.
The setting values of parameters can be set during
search.
AUA: Application easy setting
AUE: Eco-standby power setting
AUL: Multi-rating select
AU1: Automatic Acc/Dec
AU2: Toque boost macro
0.0HzSTOP
14:36
Basic parameters
0
0
0
0
0
0.0HzSTOP
14:36
Extended parameters (F ---)
0
3.2 Frequency parameters (F2 - -)
3.3 Operation parameters (F3 - -)
3.4 Motor parameters 1 (F4 - -)
3.5 Acc/dec parameters (F5 - -)
3.1 Input/output parameters (F1 -

-)
Top
Monitor
A900: Input function target 11
A901: Input function command 12
A902: Input function target 12
A903: Input function command 13
A904: Input function target 13
0.0HzSTOP
14:37
Advanced pararneters (A ---)
0
0
0
0
0
0.0HzSTOP
14:37
Communication pararneters (C ---)
0
7.2 Communication pararneters (C1 -

-)
7.3 Communication pararneters (C2 -

-)
7.4 Communication pararneters (C5 -

-)
7.5 Communication pararneters (C6 -

-)
7.1 Communication pararneters (C0 -

-)
Top
Monitor
0.0HzSTOP
14:38
Changed parameters search & edit
U—
Waiting for search
0
Top Return R(Back)
F(Next)
