E6582062
4-23 4. [Basic operation] Operation methods of motor
3
4
9
9 Press the [OK] key.
The screen returns to the [Standard mode] screen.
10 When you press the [RUN] key, the motor starts
running.
In the main area of the [Standard mode] screen,
the output frequency is displayed.
The motor accelerates according to the setting of
<ACC: Acceleration time 1>, and its frequency
changes to the frequency command value set with
<FC: Panel run frequency> and becomes stable.
In the example on the right, it is 30.0 Hz.
The following are always displayed in the status area on the upper side of the screen regard-
less of display mode.
(From the left)
• The icon is rotating
• Operation status "RUN"
• Frequency command (display contents vary depending on the setting of the parameter)
• Run command icon
11 To stop the motor, press the [STOP] key.
The motor decelerates according to the setting of <dEC: Deceleration time 1> and stops.
4. 3. 2 [Operation example 2] Switching forward/reverse
run with [FWD/REV] key during panel run
Switch the direction of rotation of the motor during run only by the operation panel.
• Make setting so that forward run/reverse run can be input from the operation panel.
• The parameter to be set is <Fr: Panel Fwd/Rev run select>.
Memo
• You can change the frequency command value by pressing the [OK] key in [Standard mode]
and displaying the setting screen of <FC: Panel
run frequency> during run.
• When you change the frequency command value with the touch wheel, the output frequency
changes accordingly.
Standard Mode
Easy Screen Copy Monitor
Hz
0.0HzSTOP
0.0
14:47
F R
Easy Screen Copy Monitor
Hz
30.0HzRUN
30.0
15:30
Standard Mode
F R
To Next Page
