Toshiba TOSVERT VF-AS3 User Manual

E6582062
4-41 4. [Basic operation] Operation methods of motor
3
4
9
13 Press the [OK] key.
The screen returns to the basic parameter screen.
14 Similarly, select <Sr2: Preset speed 2> and <Sr3:
Preset speed 3> and change the setting values.
In the example on the right, <Sr2: Preset speed 2>
is set to 10.0 Hz and <Sr3: Preset speed 3> to 15.0
Hz.
15 Press the [OK] key to return to the basic parameter screen.
16 Turn on the external switch.
Leave the two relays off.
17 When you turn on relay 1, the frequency command value of <Sr1> is enabled, and the motor
starts running.
In the main area of the [Standard mode] screen, the output frequency is displayed.
0.0HzSTOP
15:59
Basic parameters
dEC : Deceleration time 1
Sr0 : Preset speed 0
Sr3 : Preset speed 3
10.0s
0.0Hz
0.0Hz
Sr1 : Preset speed 1 20.0Hz
Sr2 : Preset speed 2 10.0Hz
F R
0.0HzSTOP
15:59
Basic parameters
dEC : Deceleration time 1
Sr0 : Preset speed 0
10.0s
0.0Hz
Sr1 : Preset speed 1 20.0Hz
Sr2 : Preset speed 2 10.0Hz
Sr3 : Preset speed 3
15.0Hz
F R

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
