5-25 5. [Fundamental operation] How to use parameters
3
4
5
9
■ Setting example
While a model with a rated current of ●● A is used at the rated load (100% load), the monitor mode
is displayed as follows:
Direction of rotation
Output current
DC bus voltage
Output voltage
Torque
Top Easy Setting
15:15
Forward
0%
119%
0%
0%
Monitor Mode
60.0Hz
RUN
Direction of rotation
Output current
DC bus voltage
Output voltage
Torque
Top Easy Setting
15:15
Forward
0.0A
476V
0V
0%
Monitor Mode
60.0Hz
RUN

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
