Toshiba TOSVERT VF-AS3 User Manual

E6582062
5-53 5. [Fundamental operation] How to use parameters
3
4
5
9
0: Frequency only
Only the frequency command is valid.
1: With function
For each preset speed commands of 1-speed to 15-speed, direction of rotation, acceleration/
deceleration time, V/f control, and torque limit can be set.
In this case, the direction of rotation of the motor is as set with <F561: Operation function (1-speed)>
to <F576: Operation function (0-speed)>, not as the input of terminal [F] or terminal [R].
Add the values of the functions to be used for setting. For example, when using the functions of Rev
run (+1) and Acc/Dec switching signal 1 (+2), set "3" (+1+2=+3).
Do not set +8, or +16 to F576.
Title Parameter name Adjustment range Default setting
F560 Preset speed operation
style
0: Frequency only
1: With function
0
Title Parameter name Adjustment range Default setting
F561 - F575 Operation function (1-
speed) to Operation
function (15-speed)
0: Fwd run
+1: Rev run
+2: Acc/Dec switching signal 1
+4: Acc/Dec switching signal 2
+8: V/f switching signal 1
+16: V/f switching signal 2
+32: Torque limit switching signal 1
+64: Torque limit switching signal 2
0
F576 Operation function (0-
speed)

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
