Toshiba TOSVERT VF-AS3 User Manual

E6582062
5. [Fundamental operation] How to use parameters 5-54
4
5
9
5. 3. 8 Setting PID control
<FPld: PID1 set value>
■ Function
This parameter is applied to process control including keeping airflow, pressure, and the amount of
flow constant.
The set value and the feedback signal (4 - 20 mA, 0 - 10 V) from the detector are compared, and the
frequency is changed toward the set value.
■ Parameter setting
■ Reference of setting
1) Selecting set value and feedback input
Set the set value of PID control with <F389: PID1 set value select> and the feedback input
value with <F360: PID1 feedback input select>.
• For <F389>, do not set the signal used for <F360>.
• When the feedback value and the set value match, the signal can be output. Assign function
"144: PID 1, 2 frequency command agreement" to the output terminals.
Title Parameter name Adjustment range Unit Default setting
FPId PID1 set value F368 to F367 Hz 0.0
0.0HzSTOP
15:27
Min: 0.0 Max: 60.0
X1000 X100 X10 X1
Hz
FPld :PlD1 set value
0.0
Basic parameter

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
