5. [Fundamental operation] How to use parameters 5-62
4
5
9
1: Japan (read only)
2: Mainly North America (read only)
3: Mainly Asia (read only)
4: Mainly Europe (read only)
5: Mainly China (read only)
All of 1 to 5 are display to check the setting. Even if you select any of them and press the [OK] key,
new setting cannot be made.
There is a mark at the right end of the region selected in the setup menu.
■ Parameters set with setup menu
Important
• While the setup menu is started, you cannot return to the previous step even if you press the
[ESC] key.
• Note that all parameters return to status of default setting and the trip history data is cleared.
Parameter title Function
Mainly
North
America
Mainly
Asia
Mainly
Europe
China Japan
FH
Maximum frequency
(Hz)
80.0 80.0 80.0 50.0 80.0
F307
Supply voltage
compensation
22223
F319
Regenerative over-flux
upper limit (%)
120 120 120 140 140
F417
Motor rated speed
(min
-1
)
*1
*1 *1 *1 *1
vLv, F171, F175, F179
Base frequency
Voltage (V)
230 230 230 200 200
460 400 400 380 400
vL, UL, F170,
F174, F178, F204,
F213, F219, F225,
F231, F237, F330,
F335, F364, F367,
F370, F426, F428,
F814, A316, A319,
A322, A346, A349,
A352, A376, A379,
A382
Frequency (Hz) 60.0 50.0 50.0 50.0 60.0
1: Japan
2: Mainly North America
3: Mainly Asia
4: Mainly Europe
0.0HzSTOP
15:30
Setup
5: Mainly China
CopyScreen
0.0HzSTOP
15:33
Standard mode
JP
Easy
Setting for Japan
Monitor
To Next Page
