E6582062
6-71 6. [Advanced] How to use parameters
3
4
6
9
3) Droop frequency
Droop frequency = <vL: Base frequency 1> x Gain 1 x Gain 2
Note that, when <vL: Base frequency 1> is over 100 Hz, this value is calculated as 100 Hz.
Reference
• How to operate the operation panel -> Refer to [3. 1. 1].
• How to switch display mode on the operation panel -> Refer to [3. 1. 2].
• Procedure to change parameter setting -> Refer to [4. 2. 3]
