E6582062
6. [Advanced] How to use parameters 6-110
4
4
6
9
6. 27. 2 Switching four types of acceleration/deceleration
<F500: Acceleration time 2>
<F501: Deceleration time 2>
<F503: Acc/Dec pattern 2>
<F504: Panel Acc/Dec select>
<F505: Acc/Dec switching frequency 1>
<F510: Acceleration time 3>
<F511: Deceleration time 3>
<F512: Acc/Dec pattern 3>
<F513: Acc/Dec switching frequency 2>
<F514: Acceleration time 4>
<F515: Deceleration time 4>
<F516: Acc/Dec pattern 4>
<F517: Acc/Dec switching frequency 3>
<F519: Unit of Acc/Dec time>
■ Function
You can set four types of options for each acceleration and deceleration time.
There are three setting methods to choose from four types.
1) Selection by the parameters
2) Switching by frequencies
3) Switching by the terminals
■ Setting of parameters
Title Parameter name Adjustment range Unit Default setting
ACC Acceleration time 1 0.0 - 6000 (600.0) s
*1
*1 Depending on capacity. For details, refer to [11. 6].
dEC Deceleration time 1 0.0 - 6000 (600.0) s
*1
F500 Acceleration time 2 0.0 - 6000 (600.0) s
*1
F501 Deceleration time 2 0.0 - 6000 (600.0) s
*1
F510 Acceleration time 3 0.0 - 6000 (600.0) s
*1
F511 Deceleration time 3 0.0 - 6000 (600.0) s
*1
F514 Acceleration time 4 0.0 - 6000 (600.0) s
*1
F515 Deceleration time 4 0.0 - 6000 (600.0) s
*1
F519 Unit of Acc/Dec time 0: -
1: 0.01 s unit (0 after execution)
2: 0.1 s unit (0 after execution)
-0
0.0HzSTOP
13:50
F500 : Acceleration time 2
Min: 0.0 Max: 6000.0
X1000 X100 X10 X1
10.0
s
1: 0.01s unit (0 after execution)
2: 0.01s unit (1 after execution)
0.0HzSTOP
13:51
0: -
F519 : Unit of Acc/Dec time
