6. 30. 4 Emergency off
<F603: Emergency off stop pattern>
<F604: Emergency DC braking time>
■ Function
Set the stop pattern for emergency off
At the time of emergency off, a trip occurs. The trip display is "E".
■ Parameter setting
■ Select the setting value for <F603: Emergency off stop pattern>
0: Trip
A trip occurs by emergency off command. The motor performs coast stop.
1: Trip after Deceleration stop
A trip occurs after deceleration stop is performed for the period of time set for <dEC: Deceleration
time 1>.
2: Trip after Emergency DC braking
The inverter stops after emergency DC braking, and a trip occurs.
Set <F251: DC braking current> and <F604: Emergency DC braking time>.
3: Trip after deceleration stop by <F515>
A trip occurs after deceleration stop is performed for the period of time set for <F515: Deceleration
time 4>.
Set <F515>.
Title Parameter name Adjustment range Unit Default setting
F603 Emergency off stop
pattern
0: Trip
1: Trip after Deceleration stop
2: Trip after Emergency DC braking
3: Trip after deceleration stop by
F515
4: Trip after Quick deceleration stop
5: Trip after Dynamic quick
deceleration stop
0
F604 Emergency DC braking
time
0.0-20.0 s 1.0
F251 DC braking current 0 - 100 % 50
F515 Deceleration time 4 0.0-6000 s
*1
*1 Depending on capacity. For details, refer to [11. 6].
0: Trip
1: Trip after Deceleration stop
2: Trip after Emergency DC brake
3: Trip after dec stop by F515
4: Trip after Quick dec stop
0.0HzSTOP
13:53
F603 : Emergency off stop pattern
