E6582062
6-125 6. [Advanced] How to use parameters
3
4
6
9
6. 30. 5 Output phase loss detection
<F605: Output phase loss detection>
■ Function
When the phase loss on the inverter output side is detected, and after a certain period of time
passed, a trip occurs. The trip display is "EPHO".
■ Parameter setting
■ How to select a setting value
0: Disabled
A trip does not occur. (Failure signal FL disabled)
1: At startup (only one time after power on)
After the power is turned on, output phase loss is detected at the first startup, and a trip occurs after
a certain period of time passed. (Failure signal FL enabled)
2: At every startup
At every startup, output phase loss is detected, and a trip occurs after a certain period of time
passed. (Failure signal FL enabled)
3: During run
A phase loss is detected during run, and a trip occurs after a certain period of time passed. (Failure
signal FL enabled)
4: At every startup + during run
At every startup and during run, a phase loss is detected, and a trip occurs after a certain period of
time passed. (Failure signal FL enabled)
5: Output shut off detection
In case you release between the motor and inverter for commercial power supply, restart the
operation with low-voltage by controlling impact after the connection at the output side is off and
connect it again. (Failure signal FL disabled)
Title Parameter name Adjustment range Default setting
F605 Output phase loss
detection
0: Disabled
1: At startup (only one time after power on)
2: At every startup
3: During run
4: At every startup + during run
5: Output shut off detection
0
0: Disabled
1: At startup (1 time after power on)
2: At every startup
3: During run
4: At every startup + during run
0.0HzSTOP
13:54
F605 : Output phase loss detect
