Toshiba TOSVERT VF-AS3 User Manual

E6582062
2. Installation and wiring 2-8
2
9
*1 Case of 100% load ND continuous operation. The heat loss for the optional external devices (input reactor, radio noise reduction filters, etc.) is not
included in the calorific values in the table.
■ Panel designing in consideration of effects of noise
The inverter generates high frequency noise. When designing the control panel, consideration must
begiven to that noise.
Examples of measures are given below.
• Wire so that the power connections and the control connections are separated. Do not place them
in the same conduit, do not run them in parallel, and do not bundle them.
• Provide shielding and twisted wires for control connection.
• Separate the input (power) and output (motor) wires of the power circuit. Do not place them in the
same conduit, do not run them in parallel, and do not bundle them.
• Be sure to ground the inverter grounding terminals.
• Install a surge absorber on any magnetic contactor and relay coils used around the inverter.
• Install radio noise reduction filters if necessary.
Input
voltage
Class
Applicable
motor
capacity
(kW)
Inverter type-form
Frame
size
Inverter
calorific value
(W) *1
Inner side
calorific value
(W) *1
Forced
air-cooled
Required
ventilation
amount
(m
3
/min)
Sealeded
cabinet
Necessary
heat discharge
surface
quantity (m
2
)
3-phase
480 V
0.75
VFAS3-
4004PC
A1
56 26 0.32 1.13
1.5 4007PC 79 28 0.45 1.58
2.2 4015PC 100 30 0.57 2.00
4.0 4022PC 140 33 0.79 2.80
5.5 4037PC 192 37 1.09 3.83
7.5 4055PC
A2
233 45 1.32 4.66
11 4075PC 323 53 1.84 6.47
15 4110PC
A3
455 62 2.58 9.10
18.5 4150PC 557 70 3.16 11.14
22 4185PC 603 71 3.42 12.06
30 4220PC
A4
770 94 4.37 15.40
37 4300PC 939 107 5.33 18.78
45 4370PC 1101 123 6.25 22.02
55 4450PC
A5
1094 132 6.21 21.88
75 4550PC 1589 175 9.02 31.78
90 4750PC 1827 199 10.37 36.54
110 4900PC
A6
2920 309 16.58 58.40
132 4110KPC 3457 358 19.62 69.13
160 4132KPC 4013 405 22.78 80.26
220 4160KPC A7 5404 452 30.68 108.08
250 4220KPC
A8
6279 606 35.64 125.58
280 4250KPC 6743 769 38.28 134.86
315 4280KPC 7749 769 43.99 154.98

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
