7-9 7. Operating using external signals
3
4
7
9
■ Function setting for the output terminals
■ Assigning two types of functions to a terminal
For the output terminals, you can assign two types of functions to the terminals [FP] and [R1A]-
[R1C].
1) Logical product (AND): Signals are output when two types of functions are
simultaneously turned ON.
In case of the terminal [FP], when you set <F139: Terminal FP, R1 logic select> = "0" or "1",
signals are output when the functions set for <F130: Terminal FP function 1> and <F137:
Terminal FP function 2> are simultaneously turned ON.
Terminal symbol Title Parameter name Adjustment range
Default
setting
FP F130
Terminal FP function 1
*1
*1 When you use the terminal [FP] as digital input, set <F669: Terminal FP switching> = "0: Digital output".
0 - 255 6
F137
Terminal FP function 2
*1
255
F669 Terminal FP switching 0: Digital output
1: Pulse train output
0
FLA-FLB-FLC F132 Terminal FL function 0 - 255 10
R1A-R1C F133 Terminal R1 function 1 0 - 255 4
F138 Terminal R1 function 2 255
R2A-R2C F134 Terminal R2 function 0 - 255 254
DQ11 F159 Terminal DQ11 function
*2
*2 Indicated optional terminals on IO extension 1 (ETB013Z) or IO extension 2 (ETB014Z), refer to E6582128 or E6582129.
0 - 255 254
DQ12 F160 Terminal DQ12 function
*2
0 - 255 254
R4 F161
Terminal R4 function
*2
0 - 255 254
R5 F162
Terminal R5 function
*2
0 - 255 254
R6 F163
Terminal R6 function
*2
0 - 255 254
R1 F135 Terminal R1 delay time 0.0 - 60.0 (s) 0.0
R2 F136 Terminal R2 delay time 0.0 - 60.0 (s) 0.0
FP
R1A-R1C
F139 Terminal FP, R1 logic
select
0: F130 and F137,
F133 and F138
1: F130 and F137,
F133 or F138
2: F130 or F137,
F133 and F138
3: F130 or F137,
F133 or F138
0
