E6582062
7. Operating using external signals 7-12
4
4
4
7
9
30 31 Braking resistor overload (OLr)
pre-alarm
150 151 PTC input pre-alarm
32 33 Emergency off trip 152 153 During Safe Torque Off (STO)
34 35 During retry 154 155 Analog input disconnecting alarm
36 37 Pattern operation end 156 157 Terminal F ON/OFF
38 39 PID deviation limit 158 159 Terminal R ON/OFF
40 41 Run/Stop 160 161 Cooling fan replacement alarm
42 43 Serious failure 162 163 Number of starting alarm
44 45 Slight failure 164 165 Light load detection 2
46 47 Commercial power/Inverter
Switching 1
166 167 During Acc
48 49 Commercial power/Inverter
Switching 2
168 169 During Dec
50 51 During cooling fan run 170 171 During constant speed run
52 53 During jog run 172 173 During DC braking
54 55 During terminal run 174 175 During hit and stop
56 57 Cumulative run time alarm 176 177 During run including servo lock
58 59 Communication option
communication time-out
178 179 During servo lock
60 61 Fwd/Rev run 180 181 For input cumulative power
62 63 Ready for run 1 182 183 Shock monitoring alarm
64 65 Ready for run 2 184 185 Number of external equipment
starting alarm
68 69 During brake 186 187 V/f switching status 1
70 71 During alarm or pre-alarm 188 189 V/f switching status 2
72 73 During Fwd speed limit 190 191 Cooling fan fault alarm
74 75 During Rev speed limit 192 193 Embedded Ethernet
communication time-out
76 77 Inverter healthy output 194 - 201 Calendar 1 - 4
78 79 RS485 communication time-out 202 203 During PID2 control
92 93 Designated data bit 0 204 205 During External PID3 control
94 95 Designated data bit 1 206 207 External PID3 deviation limit
106 107 Light load detection 1 208 209 During External PID4 control
108 109 Heavy load detection 210 211 External PID4 deviation limit
110 111 During positive torque limit 212 213 Pump control
Setting value
Output terminal function
Setting value
Output terminal function
Positive
logic
Negative
logic
(Inverse)
Positive
logic
Negative
logic
(Inverse)
