Toshiba TOSVERT VF-AS3 User Manual

E6582062
7-15 7. Operating using external signals
3
4
7
9
RX F210 RX point 1 input value -100 to 100 (%) 0
F211 RX point 1 frequency 0.0 - 590.0 (Hz) 0.0
F212 RX point 2 input value -100 to 100 (%) 100
F213 RX point 2 frequency 0.0 - 590.0 (Hz)
50.0/60.0
*1
F107 Terminal RX input voltage
select
0: 0 to +10 V
1: -10 to +10 V
0
II F216 II point 1 input value 0 - 100 (%) 20
F217 II point 1 frequency 0.0 - 590.0 (Hz) 0.0
F218 II point 2 input value 0 - 100 (%) 100
F219 II point 2 frequency 0.0 - 590.0 (Hz)
50.0/60.0
*1
AI4 F222
AI4 point 1 input value
*2
-100 to 100 (%) 0
F223
AI4 point 1 frequency
*2
0.0 - 590.0 (Hz) 0.0
F224
AI4 point 2 input value
*2
-100 to 100 (%) 100
F225
AI4 point 2 frequency
*2
0.0 - 590.0 (Hz)
50.0/60.0
*1
F148
Terminal AI4 input select
*2
1: Voltage input (0 - 10 V)
2: Voltage input (-10 to +10 V)
3: Current input (0 - 20 mA)
4: PTC input
5: PT100 (2-wire) input
6: PT100 (3-wire) input
7: PT1000 (2-wire) input
8: PT1000 (3-wire) input
9: KTY84 input
1
AI5 F228
AI5 point 1 input value
*2
-100 to 100 (%) 0
F229
AI5 point 1 frequency
*2
0.0 - 590.0 (Hz) 0.0
F230
AI5 point 2 input value
*2
-100 to 100 (%) 100
F231
AI5 point 2 frequency
*2
0.0 - 590.0 (Hz)
50.0/60.0
*1
F149
Terminal AI5 input select
*2
1: Voltage input (0 to 10V)
2: Voltage input (-10 to +10 V)
3: Current input (0 - 20 mA)
4: PTC input
5: PT100 (2-wire) input
6: PT100 (3-wire) input
7: PT1000 (2-wire) input
8: PT1000 (3-wire) input
9: KTY84 input
1
Terminal
symbol
Title Parameter name Adjustment range
Default
setting

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
