Toshiba TOSVERT VF-AS3 User Manual

E6582062
7. Operating using external signals 7-16
4
4
4
7
9
For details on switching two types of analog signals for operation, refer to [5. 4. 1].
Common F209 Analog input filter 1: Disabled
2 - 1000 (ms)
1
*3
A959 Analog input function target
11
0: Disabled
1: Terminal RR
2: Terminal RX
3: Terminal II
4: Terminal AI4
5: Terminal AI5
A961 Analog function setting
destination 11
0: Disabled
1: Acc/Dec rate (ACC.dEC etc.)
2: Upper limit frequency (UL)
3: Acc multiplication factor (FH/
ACC etc.)
4: Dec multiplication factor (FH/
dEC etc.)
5: Manual torque boost (vb etc.)
6: Stall prevention level (F601 etc.)
7: Motor OL protection current
(tHrA)
8: Speed control response (F460
etc.)
9: Droop gain (F320 etc.)
10: PID proportional gain (F362
etc.)
11: Base frequency voltage (VL
etc.)
12 - 20: -
A962 Analog input function target
21
Same as A959
A964 Analog function setting
destination 21
Same as A961
*1 The default setting value is depending on the setup menu. Refer to [5. 3. 10].
*2 Indicated optional terminals on IO extension 1 (ETB013Z), refer to E6582128.
*3 If stable operation cannot be achieved because of noise of the frequency command circuit, etc., increase the value for <F209: Analog input
filter>.
Terminal
symbol
Title Parameter name Adjustment range
Default
setting

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
