Toshiba TOSVERT VF-AS3 User Manual

E6582062
11. Table of parameters 11-10
1
9
11
F181 0181
Parameter for
manufacturer
------
F182 0182
Motor overload
protection current 2
Depending on capacity
*1
A
*1
Y
[6. 4]F183 0183
Motor overload
protection current 3
A
*1
Y
F184 0184
Motor overload
protection current 4
A
*1
Y
F185 0185
Stall prevention
level 2
10-200 (HD)
10-160 (ND)
% (A)
150 (HD)
120 (ND)
Y [6. 30. 2]
F190 0190
V/f 5-point VF1
frequency
0.0 - FH Hz 0.0 N
[5. 3. 4]
F191 0191
V/f 5-point VF1
voltage
0.0 - 125.0 % (V) 0.0 N
F192 0192
V/f 5-point VF2
frequency
0.0 - FH Hz 0.0 N
F193 0193
V/f 5-point VF2
voltage
0.0 - 125.0 % (V) 0.0 N
F194 0194
V/f 5-point VF3
frequency
0.0 - FH Hz 0.0 N
F195 0195
V/f 5-point VF3
voltage
0.0 - 125.0 % (V) 0.0 N
F196 0196
V/f 5-point VF4
frequency
0.0 - FH Hz 0.0 N
F197 0197
V/f 5-point VF4
voltage
0.0 - 125.0 % (V) 0.0 N
F198 0198
V/f 5-point VF5
frequency
0.0 - FH Hz 0.0 N
F199 0199
V/f 5-point VF5
voltage
0.0 - 125.0 % (V) 0.0 N
F200 0200
Frequency
command priority
select
0: FMOd/F207
(switched by TB)
1: FMOd/F207
(switched by F208)
--0Y
[5. 4. 1]
[6. 6. 1]
F201 0201
RR point 1 input
value
0 - 100 % 0 Y
[6. 6. 2]
[7. 3. 1]
[7. 3. 2]
F202 0202
RR point 1
frequency
0.0 - 590.0 Hz 0.0 Y
F203 0203
RR point 2 input
value
0 - 100 % 100 Y
F204 0204
RR point 2
frequency
0.0 - 590.0 Hz
50.0/
60.0
*2
Y
F205 0205 RR point 1 rate 0 - 250 % 0 Y
[6. 6. 2]
F206 0206 RR point 2 rate 0 - 250 % 100 Y
Title
Communication
No.
Parameter name Adjustment range Unit
Minimum
setting unit
(Panel/
Communication)
Default
setting
Write
during
running
*6
User
setting
Reference

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
