Toshiba TOSVERT VF-AS3 User Manual

E6582062
11-43 11. Table of parameters
1
3
9
10
11
F810 0810
Communication
frequency point
select
0: Disabled
1: RS485 (1)
2: RS485 (2)
3: Communication
option
4: Embedded Ethernet
--0Y
[6. 6. 2]
[6. 38. 1]
F811 0811
Communication
point 1 input value
0 - 100 % 0 Y
F812 0812
Communication
point 1 frequency
0.0 - FH Hz 0.0 Y
F813 0813
Communication
point 2 input value
0 - 100 % 100 Y
F814 0814
Communication
point 2 frequency
0.0 - FH Hz
50.0/
60.0
*2
Y
F820 0820
RS485 (2) baud
rate
0: 9600 bps
1: 19200 bps
2: 38400 bps
3: -
--1Y
[6. 38. 1]
F821 0821 RS485 (2) parity
0: Disabled
1: Even parity
2: Odd parity
--1Y
F823 0823
RS485 (2) time-out
time
0.0: Disabled
0.1 - 100.0
s0.0Y
F824 0824
RS485 (2) time-out
operation
1: Continue running
2, 3: -
4: Trip
5: -
6: Trip after deceleration
stop
--1Y
F825 0825
RS485 (2)
transmission wait
time
0.00 - 2.00 s 0.00 Y
F826 0826
RS485 (2) inverter
to inverter
communication
0: Follower (0Hz
command when
Leader fails)
1: Follower (continue
running when Leader
fails)
2: Follower (emergency
off when Leader fails)
3: Leader (transmit
frequency command)
4: Leader (transmit
output frequency
signal)
5: Leader (transmit
torque command)
6: Leader (transmit
output torque
command)
--0Y
F827 0827 RS485 (2) protocol
0: TOSHIBA
1: MODBUS
--0Y
Title
Communication
No.
Parameter name Adjustment range Unit
Minimum
setting unit
(Panel/
Communication)
Default
setting
Write
during
running
*6
User
setting
Reference

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
