E6582062
11. Table of parameters 11-62
1
9
11
152 153 MOT2 No. 2 motor switching
ON: No.2 motor setting + No.2 Acc/Dec + No.2 Stall (Torque
limit)
(V/f constant, <F170>, <F171>, <F172>, <F182>, <F185>,
<F500>, <F501>, <F503>)
<tHrA> (not <F182>) when <F632> = "2", "3"
OFF: No.1 motor setting + No.1 Acc/Dec + No. 1 Stall
(Torque limit)
(<Pt>, <vL>, <vLv>, <vb>, <tHrA>, <ACC>, <dEC>, <F502>,
<F601>)
[7. 2. 1]
154 155 PID3 External PID3 enabled ON: External PID3 enabled
156 157 PID4 External PID4 enabled ON: External PID4 enabled
158 159 RES2 Reset 2 ON: Reset accepted, ON -> OFF: Trip reset
162 163 PID3R
External PID3 differential/
integral reset
ON: External PID3 differential/integral reset
164 165 PID3S
External PID3 plus/minus
switching
ON: Plus/minus characteristics of <A340: PID control 3>
setting
OFF: Characteristics of <A340: PID control 3> setting
170 171 PID4R
External PID4 differential/
integral reset
ON: External PID4 differential/integral reset
172 173 PID4S
External PID4 plus/minus
switching
ON: Plus/minus characteristics of <A370: PID control 4>
setting
OFF: Characteristics of <A370: PID control 4> setting
176 177 PMPR Pump control release ON: Pump release during pump control
200 201 PWP Parameter writing locked
ON: Parameter writing locked (Reading unlocked)
OFF: <F700: Parameter reading & writing access lockout>
setting
[6. 34. 1]
[7. 2. 1]
202 203 PRWP Parameter reading locked
ON: Parameter reading & writing access lockout
OFF: <F700: Parameter reading & writing access lockout>
setting
Function number
Symbol Function Action
Reference
Positive
logic
Negative
logic
