11-61 11. Table of parameters
1
3
9
10
11
102 103 CPSW
Commercial powr run
switching
ON: Commercial power run, OFF: Inverter run
[6. 20]
[7. 2. 1]
104 105 FCHG
FMOd/F207 priority
switching
ON: <F207: Frequency command select 2> enabled
(When <F200: Frequency command priority select> =
"0")
OFF: <FMOd: Frequency command select 1> enabled
[5. 4. 1]
[7. 2. 1]
106 107 FMTB Terminal II priority
ON: Frequency command of Terminal [II] enabled
OFF: <FMOd: Frequency command select 1> enabled
[7. 2. 1]
108 109 CMTB Terminal run priority
ON: Run command of terminal enabled
OFF: <CMOd: Run command select> enabled
[5. 2. 1]
[7. 2. 1]
110 111 PWE
Parameter writing
unlocked
ON: Parameter writing unlocked
OFF: <F700: Parameter reading & writing access lockout>
setting
[6. 34. 1]
[7. 2. 1]
112 113 STSW
Speed control/Torque
control switching
ON: Torque control, OFF: Speed control [7. 2. 1]
114 115 EXCUT
External equipment
counter
ON: Count the signals (Monitor number "103" can monitor
the number of ON signal)
[6. 30. 21]
[7. 2. 1]
116 117 PI1SW PID 1, 2 switching ON: PID2, OFF: PID1 [7. 2. 1]
118 119 SS5 Preset speed switching 5 Selection of 31-speed SS1 to SS5 (5 bits)
[5. 3. 7]
[7. 2. 1]
120 121 FSTP1 Quick deceleration 1
ON: Dynamic quick deceleration
OFF: Canceled
*Operation is resumed when dynamic quick deceleration is
canceled
[7. 2. 1]
122 123 FSTP2 Quick deceleration 2
ON: Quick deceleration
OFF: Canceled
*Operation is resumed when quick deceleration is canceled
124 125 PREX Preliminary excitation ON: Preliminary excitation
126 127 BRK Brake ON: Brake closed
130 131 BRKA Brake answerback
ON: Comparison signal with output terminal function "68:
During brake release" ("E-11" trip when mismatching)
[6. 30. 15]
[7. 2. 1]
134 135 TVS Traverse operation ON: Traverse operation permission
[7. 2. 1]
136 137 RSC Rescue operation ON: Rescure operation (Low voltage operation)
138 139 PMPSW Pump control switching ON: Pump switching during pump control
140 141 SLOWF Fwd slowdown
ON: Forward run toward the setting value of <F383: Hit and
stop frequency>
142 143 STOPF Fwd stop ON: Stop (Forward run only)
144 145 SLOWR Rev slowdown
ON: Reverse run toward the setting value of <F383: Hit and
stop frequency>
146 147 STOPR Rev stop ON: Stop (Reverse run only)
148 149 SLOFR Fwd/Rev slowdown ON: Stop (Forward/Reverse run)
150 151 HSC Hit and stop clear ON: Hit and stop cleared
Function number
Symbol Function Action
Reference
Positive
logic
Negative
logic
