Toshiba TOSVERT VF-AS3 User Manual

E6582062
2-59 2. Installation and wiring
2
3
9
10
2) When an external power supply is used
The terminal [PLC] is used to connect to an external power supply or to separate a terminal
from other input or output terminals.
Sink/source logic is set by the slide switch [SW1].
Refer to "■Switching of slide switch of control terminal block."
Sink logic
Output
Output
InverterProgrammable
controller
Input
Common
F
24Vdc
CC
Input
Common
P24
24Vdc
FP
Source logic
Output
PLC
SINK
SOURCE
SW1
PLC
SINK
SOURCE
SW1
InverterProgrammable
controller
Input
Common
F
24Vdc
P24
PLC
SINK
SOURCE
SW1
Sink logic
Output
Output
InverterProgrammable
controller
Input
Common
F
24Vdc24Vdc
24Vdc
SW1:PLC side
Input
PLC
FP

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
