E6581158
E-27
5
2) Preset-speed frequency setting
Set the speed (frequency) of the number of steps necessary.
Setting from speed 1 to speed 7
Title Funtion Adjustment range Setting value
UT UT
Preset-speed operation frequencies
1-7
NN WN(Hz) 0.0
Setting from speed 8 to speed 15
Title Function Adjustment range Setting value
H H
Preset-speed operation frequencies
8-15
NN WN(Hz) 0.0
Examples of preset-speed contact input signals: Slide switch SW1 set to sink logic
O: ON -: OFF (Speed commands other than preset-speed commands are valid when all are OFF)
Preset-speed
Terminal
123456789101112131415
S1-CC { - { - { - { - { - { - { - {
S2-CC - {{ --{{ --{{ --{{
S3-CC---{{{{ ----{{{{
RES-CC-------{{{{{{{{
, Terminal functions are as follows.
Terminal S1.............Input terminal function selection 4 (S1)
H= (Preset-speed command 1: SS1)
Terminal S2.............Input terminal function selection 5 (S2)
H= (Preset-speed command 2: SS2)
Terminal S3.............Input terminal function selection 6 (S3)
H= (Preset-speed command 3: SS3)
Terminal RST..........Input terminal function selection 3 (RES)
H= (Preset-speed command 5: SS4)
, SS4 is not allocated to standard default setting. Use the input terminal function selection to allocate SS4
an idle terminal. In the above example the RES terminal is used for SS4.
CC
S1
S2
RES
S3
