(1) Assigning one function to an output terminal
Terminal
symbol
Title Function Adjustment range Default setting
RY - RC
H
Output terminal selection 1A 4 (Low-speed de-
tection signal)
OUT - NO
H
Output terminal selection 2A 6 (Designated fre-
quency reach)
FL
(A, B, C）
H
Output terminal selection 3
0-255
(See section 11.)
10(Failure FL)
, When assigning one function to each output terminal, set parameters H to H only
Do not change but leave parameters H to H as they were set by default.
(Standard default setting: H=255, H=255, H=0)
(2) Assigning two functions to a group of terminals
A signal is sent out when the two functions assigned are activated simultaneously.
Terminal
symbol
Title
Function
Adjustment range Default setting
RY-RC
H
Output terminal selection 1A 4 (Low-speed de-
tection signal)
OUT-NO
H
Output terminal selection 2A 6 (Designated fre-
quency reach)
RY-RC
H
Output terminal selection 1B
OUT-NO
H
Output terminal selection 2B
0-255
(See section 11.)
255 (Always ON)
, Two different functions can be assigned to terminals RY-RC and terminals OUT-NO.
, If parameter H is set to  (default), a signal will be sent out when the two functions assigned are acti-
vated simultaneously.
Terminals RY-RC: Send out a signal when the functions assigned with H and H are activated
simultaneously.
Terminals OUT-NO: Send out a signal when the functions assigned with H and H are activated
simultaneously.
, Timing chart
ON
OFF
ON
OFF
ON
OFF
H
(F137)
H
(F138)
RY-RC output
(OUT-NO)
