6.3.4 Comparing the frequency command values
H : Frequency command agreement detection range
HOQF
: Frequency setting mode selection 1
H
: Frequency setting mode selection 2
• Function
If the frequency command value specified using HOQF (or H) almost agrees with the
frequency command value from the VA terminal with an accuracy of ± the setting of H, an ON
or OFF signal will be sent out.
Q Frequency command value and agreement detection range parameter setting
Title Function Adjustment range Default setting
H
Frequency command agreement detection
range
0.0 ∼ HJ ҏ(Hz)
2.5
HOQF Frequency setting mode selection 1 0
H Frequency setting mode selection 2
0-6
(See Section 11, K-1,
5)
1
Note: To put out signals to RY-RC, OUT or FLA-FLB-FLC, set H, H, or H respectively to
52 or 53.
or
+
ON
OFF
ON
OFF
Frequency command value
Frequency command matching signal
Frequency command
matching signal: Inverted
Between RY and RC terminals
Between P24 and OUT terminals
FLA-FLC-FLB
VIA
-
Note: This function can be used, for example, to send out a signal indicating whether the amount of process-
ing and the amount of feedback agree with each other when the PID function is in use.
For an explanation of the PID function, see 6.16.
