6.18.2 Selecting an acceleration/deceleration pattern
H
: Acceleration time 2
H
: Deceleration time 2
H
: Acceleration/deceleration 2 pattern
H
: Selecting an acceleration/deceleration pattern
H
: Acceleration/deceleration 1 and 2 switching frequency
H
: Acceleration time 3
H
: Deceleration time 3
H
: Acceleration/deceleration 3 pattern
H
: Acceleration/deceleration 2 and 3 switching frequency
• Function
Three acceleration times and three deceleration times can be specified individually. A method of
selection or switching can be selected from among the following:
1) Selection by means of parameters
2) Switching by changing frequencies
3) Switching by means of terminals
Title Function Adjustment range Default setting
H Acceleration time 2 0.0-3200 [sec] 10.0
H Deceleration time 2 0.0-3200 [sec] 10.0
H
Selecting an acceleration/deceleration
pattern
: Acceleration/deceleration 1
pattern, : Acceleration/deceleration
2 pattern, :Acceleration/deceleration
3 pattern
1
H Acceleration time 3 0.0-3200 [sec] 10.0
H
Deceleration time 3 0.0-3200 [sec] 10.0

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
