E6581158
F-59
6
Q How to set parameters
a) Operating method: Terminal input
Set the operation control mode selection EOQF to .
b) Use the S2 and S3 terminals for switching. (Instead, other terminals may be used.)
S2: Acceleration/deceleration switching signal 1
S3: Acceleration/deceleration switching signal 2
Title Function Adjustment range Setting value
H Input terminal selection #5 (S2) 0-64
5 (the second
acceleration/de
celeration
mode
selection)
H
Input terminal selection #6 (S3) 0-64
58 (the third
acceleration/de
celeration
mode
selection)
Q Acceleration/ deceleration pattern
Acceleration/deceleration patterns can be selected individually, using the acceleration/deceleration 1, 2
and 3 parameters.
1) Linear acceleration/deceleration
2) S-pattern acceleration/deceleration 1
3) S-pattern acceleration/deceleration 2
Title Function Adjustment range Setting value
H Acceleration/ deceleration 1 pattern
: Linear, : S-pattern 1, : S-
pattern 2
0
H Acceleration/ deceleration 2 pattern
: Linear, : S-pattern 1, : S-
pattern 2
0
H Acceleration/ deceleration 3 pattern
: Linear, : S-pattern 1, : S-
pattern 2
0
+ For an explanation of acceleration/deceleration patterns, see 6.18.1.
+ Both the settings of the S-pattern lower-limit and upper-limit adjustment parameters (H and
H) are applied to any acceleration/deceleration S-pattern.
